| Quantity: | |
|---|---|
75W/85W/135W/150W
Lilon
75W/85W/135W/150W
100
CE
3 years
| Model | LK150-0840500 | 126YYYY | 168YYYY | 210YYYY | 252YYYY | 294YYYY | 336YYYY | 378YYY | 420YYYY | 432YYY | 546YYY |
| XXX-042-588 represents the output voltage, ranging from 4.2V to 63Vdc. YYYY=0050-0500 represents the output current, ranging from 0.5A to 5.0A. | |||||||||||
| Max Power | 75W | ||||||||||
| Input Voltage | Adjustment range: AC 90-264V (For mains voltage below 120V, please reserve about 30% of output power capacity) Standard voltage: 100-240VAC | ||||||||||
| Output Voltage Range | 8.4V | 12.6V | 16.8V | 21V | 25.2V | 29.4V | 33.6V | 37.8V | 42V | 43.2V | 54.6V |
| Output Current Range | 5.0A | 5.0A | 4.0A | 3.3A | 2.5A | 2.4A | 2.0A | 1.8A | 1.5A | 1.5A | 1.2A |
| Size | 124*56.4*31.8MM | ||||||||||
| Safety certificate | CCC、CE、FCC、ROHS、ETL、KC、CB、PSE | ||||||||||
| Model | LK150-1261000 | 168YYYY | 200YYYY | 220YYYY | 252YYYY | 294YYYY | 336YYYY | 378YYY | 420YYYY | 546YYY | 576YYY | 588YYY |
| XXX-042-672 represents the output voltage, ranging from 4.2 to 67.2Vdc. YYYY=0050-0600 represents the output current, ranging from 0.5A to 10.0A. | ||||||||||||
| Max Power | 135W | |||||||||||
| Input Voltage | Adjustment range: AC 90-264V (For mains voltage below 120V, please reserve about 30% of output power capacity) Standard voltage: 100-240VAC | |||||||||||
| Output Voltage Range | 12.6V | 16.8V | 20V | 22V | 25.2V | 29.4V | 33.6V | 37.8V | 42V | 54.6V | 57.6V | 58.8V |
| Output Current Range | 10.0A | 7.0A | 5.0A | 5.0A | 5.0A | 4.0A | 3.5A | 3.0A | 3.0A | 2.0A | 2.0A | 2.0A |
| Size | 172*72.5*33MM | |||||||||||
| Safety certificate | CCC、CE、FCC、ROHS、ETL、KC、CB、PSE | |||||||||||
| Model | LK150-1261100 | 168YYYY | 200YYYY | 220YYYY | 252YYYY | 294YYYY | 336YYYY | 378YYY | 420YYYY | 546YYY | 576YYY | 588YYY | 672YYY |
| XXX-042-672 represents the output voltage, ranging from 4.2 to 67.2Vdc. YYYY=0050-0600 represents the output current, ranging from 0.5A to 11.0A. | |||||||||||||
| Max Power | 150W | ||||||||||||
| Input Voltage | Adjustment range: AC 90-264V (For mains voltage below 120V, please reserve about 30% of output power capacity) Standard voltage: 100-240VAC | ||||||||||||
| Output Voltage Range | 12.6V | 16.8V | 20V | 22v | 25.2V | 29.4V | 33.6V | 37.8V | 42V | 54.6V | 57.6V | 58.8V | 67.2V |
| Output Current Range | 11.0A | 8.0A | 7.0A | 6.5A | 5.5A | 5.0A | 4.0A | 3.8A | 3.5A | 2.8A | 2.5A | 2.5A | 2.2A |
| Size | 172*72.5*33MM | ||||||||||||
| Safety certificate | CCC、CE、FCC、ROHS、ETL、KC、CB、PSE | ||||||||||||
| Model | LK150-0840500 | 126YYYY | 168YYYY | 210YYYY | 252YYYY | 294YYYY | 336YYYY | 378YYY | 420YYYY | 432YYY | 546YYY |
| XXX-042-588 represents the output voltage, ranging from 4.2V to 63Vdc. YYYY=0050-0500 represents the output current, ranging from 0.5A to 5.0A. | |||||||||||
| Max Power | 75W | ||||||||||
| Input Voltage | Adjustment range: AC 90-264V (For mains voltage below 120V, please reserve about 30% of output power capacity) Standard voltage: 100-240VAC | ||||||||||
| Output Voltage Range | 8.4V | 12.6V | 16.8V | 21V | 25.2V | 29.4V | 33.6V | 37.8V | 42V | 43.2V | 54.6V |
| Output Current Range | 5.0A | 5.0A | 4.0A | 3.3A | 2.5A | 2.4A | 2.0A | 1.8A | 1.5A | 1.5A | 1.2A |
| Size | 124*56.4*31.8MM | ||||||||||
| Safety certificate | CCC、CE、FCC、ROHS、ETL、KC、CB、PSE | ||||||||||
| Model | LK150-1261000 | 168YYYY | 200YYYY | 220YYYY | 252YYYY | 294YYYY | 336YYYY | 378YYY | 420YYYY | 546YYY | 576YYY | 588YYY |
| XXX-042-672 represents the output voltage, ranging from 4.2 to 67.2Vdc. YYYY=0050-0600 represents the output current, ranging from 0.5A to 10.0A. | ||||||||||||
| Max Power | 135W | |||||||||||
| Input Voltage | Adjustment range: AC 90-264V (For mains voltage below 120V, please reserve about 30% of output power capacity) Standard voltage: 100-240VAC | |||||||||||
| Output Voltage Range | 12.6V | 16.8V | 20V | 22V | 25.2V | 29.4V | 33.6V | 37.8V | 42V | 54.6V | 57.6V | 58.8V |
| Output Current Range | 10.0A | 7.0A | 5.0A | 5.0A | 5.0A | 4.0A | 3.5A | 3.0A | 3.0A | 2.0A | 2.0A | 2.0A |
| Size | 172*72.5*33MM | |||||||||||
| Safety certificate | CCC、CE、FCC、ROHS、ETL、KC、CB、PSE | |||||||||||
| Model | LK150-1261100 | 168YYYY | 200YYYY | 220YYYY | 252YYYY | 294YYYY | 336YYYY | 378YYY | 420YYYY | 546YYY | 576YYY | 588YYY | 672YYY |
| XXX-042-672 represents the output voltage, ranging from 4.2 to 67.2Vdc. YYYY=0050-0600 represents the output current, ranging from 0.5A to 11.0A. | |||||||||||||
| Max Power | 150W | ||||||||||||
| Input Voltage | Adjustment range: AC 90-264V (For mains voltage below 120V, please reserve about 30% of output power capacity) Standard voltage: 100-240VAC | ||||||||||||
| Output Voltage Range | 12.6V | 16.8V | 20V | 22v | 25.2V | 29.4V | 33.6V | 37.8V | 42V | 54.6V | 57.6V | 58.8V | 67.2V |
| Output Current Range | 11.0A | 8.0A | 7.0A | 6.5A | 5.5A | 5.0A | 4.0A | 3.8A | 3.5A | 2.8A | 2.5A | 2.5A | 2.2A |
| Size | 172*72.5*33MM | ||||||||||||
| Safety certificate | CCC、CE、FCC、ROHS、ETL、KC、CB、PSE | ||||||||||||
