| Quantity: | |
|---|---|
| Model | LK150-1262000 | 1681800 | 2521200 | 2941100 | 4200800 | 5460600 | 6720500 | 7200400 |
| (XXX=042-672，Represents output voltage, ranging from 4.2-67.2Vdc:YYYY=0050-0600, represents output current, ranging from 0.5A-6.0A) | ||||||||
| Max.Power | 300W | |||||||
| Input Voltage | Adjustment range: AC 90-264V (If the voltage is lower than 120V mains, please reserve about 30% of the output power margin). Standard voltage: 100-240VAC | |||||||
| Output Voltage Range | 12.6V | 16.8V | 25.2V | 29.4V | 42V | 54.6V | 67.2V | 72V |
| Output Current Range | 20A | 18A | 12.0A | 11.0A | 8.0A | 6.0A | 5.0A | 4.0A |
| Size | ||||||||
| Safety certificate | CCC、CE、FCC、ROHS、ETL、KC、CB、PSE | |||||||
| Model | LK150-1262000 | 1681800 | 2521200 | 2941100 | 4200800 | 5460600 | 6720500 | 7200400 |
| (XXX=042-672，Represents output voltage, ranging from 4.2-67.2Vdc:YYYY=0050-0600, represents output current, ranging from 0.5A-6.0A) | ||||||||
| Max.Power | 300W | |||||||
| Input Voltage | Adjustment range: AC 90-264V (If the voltage is lower than 120V mains, please reserve about 30% of the output power margin). Standard voltage: 100-240VAC | |||||||
| Output Voltage Range | 12.6V | 16.8V | 25.2V | 29.4V | 42V | 54.6V | 67.2V | 72V |
| Output Current Range | 20A | 18A | 12.0A | 11.0A | 8.0A | 6.0A | 5.0A | 4.0A |
| Size | ||||||||
| Safety certificate | CCC、CE、FCC、ROHS、ETL、KC、CB、PSE | |||||||
