| Quantity: | |
|---|---|
350W
Lilon
Certifications:CCC,CE,FCC,ROHS,ETL,KC,CB,PSE
Model | LK150- 1261500 | 144YYYY | 168YYYY | 220YYYY | 252YYYY | 294YYYY | 336YYYY | 378YYY | 420YYYY | 546YYY | 588YYY | 672YYY | 714YYY |
XXX-042-672 represents the output voitage,ranging from 4.2 to 84Vdc. YYYY=0050-0600 represents the output current,ranging from 0.5A to 15.0A. | |||||||||||||
Max Power | 350W | ||||||||||||
Input Voltage | Adjustment range:AC90-264V(For mains voltage below 120V,please reserve about 30%of output power capacity) Standard voltage:100-240VAC | ||||||||||||
Output Voltage Range | 12.6V | 14.4V | 16.8V | 22V | 25.2V | 29.4V | 33.6V | 37.8V | 42V | 54.6V | 58.8V | 67.2V | 71.4V |
Output Current Range | 15.0A | 15.0A | 15.0A | 10.0A | 12.0A | 10.0A | 10.0A | 8.0A | 8.0A | 6.0A | 5.5A | 5.0A | 4.0A |
Size | 206.4*107.4*55.4MM | ||||||||||||
Safety certificate | CCC、CE、FCC、ROHS、ETL、KC.CB、PSE | ||||||||||||
Certifications:CCC,CE,FCC,ROHS,ETL,KC,CB,PSE
Model | LK150- 1261500 | 144YYYY | 168YYYY | 220YYYY | 252YYYY | 294YYYY | 336YYYY | 378YYY | 420YYYY | 546YYY | 588YYY | 672YYY | 714YYY |
XXX-042-672 represents the output voitage,ranging from 4.2 to 84Vdc. YYYY=0050-0600 represents the output current,ranging from 0.5A to 15.0A. | |||||||||||||
Max Power | 350W | ||||||||||||
Input Voltage | Adjustment range:AC90-264V(For mains voltage below 120V,please reserve about 30%of output power capacity) Standard voltage:100-240VAC | ||||||||||||
Output Voltage Range | 12.6V | 14.4V | 16.8V | 22V | 25.2V | 29.4V | 33.6V | 37.8V | 42V | 54.6V | 58.8V | 67.2V | 71.4V |
Output Current Range | 15.0A | 15.0A | 15.0A | 10.0A | 12.0A | 10.0A | 10.0A | 8.0A | 8.0A | 6.0A | 5.5A | 5.0A | 4.0A |
Size | 206.4*107.4*55.4MM | ||||||||||||
Safety certificate | CCC、CE、FCC、ROHS、ETL、KC.CB、PSE | ||||||||||||
