75W/85W/135W/150W Lithium Battery Charger/Power Adapter

Home » Products » Output Voltage » 12V Lithium Battery Charger » 75W/85W/135W/150W Lithium Battery Charger/Power Adapter

Share to:

75W/85W/135W/150W Lithium Battery Charger/Power Adapter

√ Red and green LED indicators for charging status
√ Two-stage charging characteristics
√ Universal AC input range

√ No-load power consumption<1.5W
√ Protection features:Short-circuit,over-voltage,under-voltage,over-current,reverse polarity,and backflow

√ Natural air cooling
√ 3-year warranty
√ Safety certifications:CCC,CE,FCC,ROHS,ETL,KC,CB,PSE

Availability:

Quantity:



Inquire Add to Basket

Model:
75W/85W/135W/150W
Brand:
Lilon

Certifications:CCC,CE,FCC,ROHS,ETL,KC,CB,PSE

For more details, please contact us at info@liloncharger.com

Model	LK150- 0840500	126YYYY	168YYYY	210YYYY	252YYYY	294YYYY	336YYYY	378YYY	420YYYY	432YYY	546YYY
	XXX-042-588 represents the output voltage,ranging from 4.2V to 63Vdc. YYYY=0050-0500 represents the output current,ranging from 0.5A to 5.0A.
Max Power	75W
Input Voltage	Adjustment range:AC 90-264V(For mains voltage below 120V,please reserve about 30%of output power capacity) Standard voltage:100-240VAC
Output Voltage Range	8.4V	12.6V	16.8V	21V	25.2V	29.4V	33.6V	37.8V	42V	43.2V	54.6V
Output Current Range	5.0A	5.0A	4.0A	3.3A	2.5A	2.4A	2.0A	1.8A	1.5A	1.5A	1.2A
Size	12456.431.8MM
Safety certificate	CCC、CE、FCC、ROHS、ETL、KC、CB、PSE

Model	LK150- 1260600	168YYYY	210YYYY	252YYYY	294YYYY	336YYYY	378YYY	420YYYY	432YYY	546YYY	576YYY
	XXX-042-672 represents the output voltage,ranging from 4.2V to 67.2Vdc; YYYY=0050-0600 represents the output current,ranging from 0.5A to 6.0A.
Max Power	85W
Input Voltage	Adjustment range:AC 90-264V(For mains voltage below 120V,please reserve about 30%of output power capacity) Standard voltage:100-240VAC
Output Voltage Range	12.6V	16.8V	21V	25.2V	29.4V	33.6V	37.8V	42V 2.0A	43.2V	54.6V	57.6V
Output Current Range	6.0A	5.0A	4.0A	3.0A	3.0A	2.5A	2.0A	42V 2.0A	2.0A	1.5A 1.5A
Size	145.359.832.2MM
Safety certificate	CCC、CE、FCC、ROHS、ETL、KC、CB、PSE

Model

LK150-

1261000

168YYYY

200YYYY

220YYYY

252YYYY

294YYYY

336YYYY

378YYY

420YYYY

546YYY

576YYY

588YYY

XXX-042-672 represents the output voltage,ranging from 4.2 to 67.2Vdc. YYYY=0050-0600 represents tne output current,ranging trom 0.5A to 10.0A.

Max Power

135W

Input Voltage

Adjustment range:AC 90-264V(For mains voltage below 120V,please reserve about 30%of output power capacity) Standard voltage:100-240VAC

Output Voltage

Range

12.6V

16.8V

20V

22V

25.2V

29.4V

33.6V

37.8V

42V

54.6V

57.6V

58.8V

Output Current

Range

10.0A

7.0A

5.0A

4.0A

3.5A

3.0A

2.0A

Size

172*72.5*33MM

Safety certificate

cCC、CE、FCC、ROHS、ETL、KC、CB、PSE

Model	LK150-1261200	1680900	2520500	2940500	4200350	5460280	6720250	7200200
	(XXX=042-672, representing the output voltage, ranging from 4.2-67.2Vdc; YYYY=0050-0600, representing the output current, ranging from 0.5A-6.0A)
Max.Power	150W
Input Voltage	Adjustment range: AC 90-264V(If the voltage is lower than 120V mains, please reserve about 30% of the output power margin). Standard voltage: 100-240VAC
Output Voltage Range	12.6V	16.8	25.2V	29.4V	42V	54.6V	67.2V	72
Output Current Range	12A	9.0A	5.0A	5.0A	3.5	2.8A	2.5A	2.0A
Size	1727634.5mm
Safety certificate	CCC、CE、FCC、ROHS、ETL、KC、CB、PSE
