(XXX=042-672，Represents the output voltage, ranging from 4.2 to 67.2Vdc:YYYY=0050-0600, represents the output current, ranging from 0.5A to 6.0A)
Max.power
248W
lnput Voltage
Adjustment Range：AC 90-264V (The voltage is lower than 120V mains power. Please reserve about 30% of the output power margin. ) Standard voltage: 100-240VAC
Output Voltage Range
12.6V
16.8V
25.2V
29.4V
42V
54.6V
67.2V
72V
Output Current Range
15A
13A
9.0A
9.0A
5.0A
4.0A
4.0A
3.0A
Size
185.4*76.5*38.5mm
Safety certificate
CCC、CE、FCC、ROHS、ETL、KC、CB、PSE
Model
LK150-1261500
1681300
2520900
2940900
4200500
5460400
6720400
7200300
(XXX=042-672，Represents the output voltage, ranging from 4.2 to 67.2Vdc:YYYY=0050-0600, represents the output current, ranging from 0.5A to 6.0A)
Max.power
248W
lnput Voltage
Adjustment Range：AC 90-264V (The voltage is lower than 120V mains power. Please reserve about 30% of the output power margin. ) Standard voltage: 100-240VAC
